QJ-Type Deep well irrigation pump | low noise, and minimal vibration | Corrosion resistance and durability| Cost Effective
- FOB Price
US $880.01 - 5 piece
US $845.06 - 10 piece
US $789.011 - 15 piece
- group name
- Submersible pump
- Min Order
- 1 piece
- brand name
- ZHONGDA PUMPS
- model
- QH Stainless Stell Deep-well Pump
- Nearest port for product export
- Guangzhou, Shanghai, Shenzhen, Qingdao
- Delivery clauses under the trade mode
- FOB, CIF, EXW
- Acceptable payment methods
- T/T, L/C
- update time
- Fri, 03 Apr 2026 11:50:43 GMT
Paramtents
Material Cast iron, cast steel, stainless steel
Capacity As Customer Requirements
Max Head As Customer Requirements
Colour customizable
Packging & Delivery
-
Min Order1 piece
Briefing
Pump equipment widely used in agricultural irrigation, industrial water supply, domestic water use and other fields
Detailed
- Product Introduction
- Product Features
- Scope of Application
- Structural Drawings
- Performance Parameters
- Data Download
Product Introduction
QJ stainless steel deep well pump is a high-performance water pump specially designed for deep well water extraction, widely used in agricultural irrigation, industrial water supply, domestic water use and other fields. Its core feature is that it is made of stainless steel, which has excellent corrosion resistance and durability, making it particularly suitable for extracting groundwater containing corrosive substances or for occasions with high water quality requirements.
Model Description:
For example, 150QJ32-128/22, where:
✔ QJ: indicates the type of vertical multi-stage deep well pump.
✔ 150: Indicating that the applicable wellbore diameter is not less than 150mm.
✔ 32: represents the pump's flow rate (m3/h).
✔ 128: represents the pump's head (m).
✔ 22: Indicate the matching motor power (kW)
✔ 150: Indicating that the applicable wellbore diameter is not less than 150mm.
✔ 32: represents the pump's flow rate (m3/h).
✔ 128: represents the pump's head (m).
✔ 22: Indicate the matching motor power (kW)
Product Features:
- - Excellent material: The main components such as the pump body and impeller are made of stainless steel (such as 304 or 316 stainless steel), which has strong corrosion resistance and is suitable for various water quality environments.
- - High efficiency and energy saving: Advanced hydraulic model design ensures high operating efficiency, low energy consumption, and economic practicality.
- - Compact structure: The pump body is designed compactly, easy to install, and suitable for deep wells with smaller diameters.
- - Stable operation: The motor is directly connected to the pump body, ensuring smooth operation, low noise, and minimal vibration.
- - Long service life: The stainless steel material and precise manufacturing process guarantee the durability of the pump and extend its service life.
- - Easy maintenance: The modular design makes disassembly and repair convenient, reducing maintenance costs.
Scope of Application:
- Agricultural irrigation: Extracting groundwater from deep wells to meet the irrigation needs of farmland.
- Industrial water supply: Providing a stable water source for industrial production, especially suitable for industries with high water quality requirements such as chemical engineering and pharmaceuticals.
- Domestic water supply: Used for the supply of domestic water in rural and urban areas, ensuring the safety of drinking water.
- Mine drainage: Applicable for mine drainage and groundwater extraction.
- Seawater desalination: Some models can be used for water lifting operations in seawater desalination systems.
Structural Drawings:
Performance Parameters:
NO. | Model | Flow Rate | Head | Motor Power | Outer Diameter | Cable Section | Height | Weight | |
m3/h | m | kW | mm | mm2 | mm | kg | |||
150QJ10-28/3 | 10 | 28 | 3 | 143 | 2.5 | 1280 | 59 | ||
150QJ20-38/4 | 20 | 38 | 4 | 143 | 4 | 1425 | 75 | ||
150QJ32-60/11 | 32 | 60 | 11 | 143 | 6 | 2010 | 120 | ||
150QJ40-105/22 | 40 | 105 | 22 | 143 | 16 | 3360 | 242 | ||
200QJ20-260/37 | 20 | 260 | 37 | 184 | 25 | 3020 | 290 | ||
200QJ32-340/55 | 32 | 340 | 55 | 184 | 50 | 4160 | 545 | ||
200QJ50-255/63 | 50 | 255 | 63 | 184 | 50 | 3710 | 458 | ||
200QJ80-204/75 | 80 | 204 | 75 | 184 | 50 | 3740 | 410 | ||
250QJ100-200/90 | 100 | 200 | 90 | 233 | 50 | 3065 | 469 | ||
250QJ125-250/132 | 125 | 250 | 132 | 235 | 95 | 3565 | 701 | ||
250QJ140-253/150 | 140 | 253 | 150 | 235 | 95 | 3700 | 719 | ||
250QJ150-240/185 | 150 | 240 | 185 | 235 | 70X2 | 3928 | 781 | ||
300QJ180-260/200 | 180 | 260 | 200 | 281 | 70X2 | 4670 | 1062 | ||
300QJ200-264/220 | 200 | 264 | 220 | 281 | 95X2 | 4980 | 1142 | ||
300QJ240-247/260 | 300 | 247 | 260 | 360 | 120X2 | 4885 | 1284 | ||
300QJ320-217/300 | 320 | 217 | 300 | 360 | 120X2 | 4265 | 1243 | ||
... | ... | ... | ... | ... | ... | ... | ... | ... | |
*For more models, please download our catalogue or contact us.
Data Download:
QJ-type multi-stage DEep well pump
